About Element Longmont Environmental

Element Longmont Environment is a full-service testing laboratory offering environmental testing capabilities including thermal cycling, acceleration, classical shock and vibration testing.

Our environmental and dynamic testing capabilities give you a single source to meet the dynamic and environmental requirements of MIL-STD-810, MIL-STD-461, RTCA DO-160 and others.

Client Portal

NTS Labs - Lab Insight Client Login

Our team of over 9,000 Engaged Experts in North America, Europe, The Middle East, Australia, Asia and Africa are ready to help you.

Make an inquiry today



Element Longmont Environmental Specialties

Vibration Testing Capabilities at Element Longmont

• Seismic Test
• Horizontal Seismic: 60″ x 48″ mounting table
• horizontal displacement 12″
• 21,000 lbs. force
• 40 IPS
• .1 Hz – 500 Hz
• Meets NEBS GR63, Zone 4 Earthquake, Transportation Vibration, and Reliability Testing needs
• Vertical Seismic: 48: x 48″ to 96″ x 96″ mounting table
• vertical displacement 12″
• 21,000 lbs. force
• 40 IPS velocity
• .1 Hz – 500 Hz frequency range
• Meets NEBS GR63, Zone 4 Earthquake, Transportation Vibration and Reliability testing needs.

• Servo Hydraulic Shaker: horizontal load capacity 2,5000 lbs. Meets MIL-STD-810 and RTCA DO-160

• Loose Load Vibration: repetitive shock, MIL-STD, ASTM, and ISTA, loose cargo testing

• Electrodynamic Vibration
• Ling 335 Horizontal vibration table, 18,000 force lbs, 5Hz – 3,000Hz, 1 inch diameter stroke. Sine, Random and Shock capable
• Ling 335 Horizontal vibration table, 30,000 force lbs, 5Hz – 5,000Hz, 2 inch diameter stroke. Sine, Random and Shock capable

Mechanical Impact and Shock Testing Systems at Element Longmont

• TITL Tester: Center of gravity and tipping point testing for palletized items and rack equipment
• Horizontal Impact Test System (HITS): 90″ x 72″ platform produces half sine and square waveforms. Simulates truck docking railcar coupling, pallet marshaling, transportation testing.
• Acceleration – 3 foot radius centrifuge, 100 G’s, slip rings, 15 single channels with ground, 2 coaxial and 7 low noise single channels, Crash Safety
• Pyro Shock: MIL-STD-810, Method 517, NASA-STD-7003
• Drop Shock, Package Drop: 4′ x 4′ platform, programmable shock system for half sine, square wave, trapezoidal shock. Damage boundary assessment, free fall drop of large items.
• High Velocity (G) Shock: 6″ mounting surface, small test articles, acceleration to 10,000 G’s (bungee assisted), 0.5 min/sec to 1 min/sec. Evaluates disc drives, rocket velocity, etc.
• Compression Testing, Box container crush testing: 4′ x 4′ package area, 15,000 pounds capacity, simulates stacking and warehousing.
• Precision Package Drop Test: ISTA and ASTM free fall drop of packages

Temperature, Humidity, Altitude Testing Capabilities at Element Longmont

• Temperature and Humidity Chamber:
• 20′ x 17′ x 12′ man-rated drive-in chamber
• 8 foot wide door
• Temperature Ranges: -76°F to 320°F, -60°C to 160°C
• Temperature Transition Rate: 1°C/min

• Temperature and Humidity Chamber:
• 7′ x 7′ x 27′
• Temperature Ramp Rate: 20°C/min
• Temperature Range: -70°C/min to + 170°C/min, 5 – 95% Relative Humidity

• Temperature Altitude Chamber:
• 36″ x 36″ x 36″
• Altitude Range from -2,000 ft to 200,000 ft
• Temperature Ramp Rate: 10°C/min
• Temperature Range: -70°C/min to + 170°C/min
• Meets MIL-STD-810, RTCA DO-160 and IEC.

• Thermal Shock Chamber:
• Three 27 cubic foot zones
• Temperature Range: -70°C to -170°C
• 3 second transfer time.

Temperature with Vibration (AGREE) Testing at Element Longmont

• Servo Hydraulic Temperature and Vibration:
• 71″ x 53″ x 65″
• 48″ x 48″ mounting table
• Temperature Range -70°C to + 177°C
• Shaker displacement 3 inch diameter
• 41 IPS Velocity
• Meets MIL-STD-810, ISTA, and ASTM.

• Electrodynamic Temperature and Vibration:
• 71″ x 53″ x 48″ mounting table
• Temperature Range -70°C to + 177°C
• Shaker displacement 1 inch diameter
• 36″ Head Expander
• 8,000 lbs force.

Other Environmental Testing at Element Longmont

• HALT Highly Accelerated Life Testing, HASS Highly Accelerated Stress Screening:
• 4′ x 4′ x 4′ Chamber
• Combined temperature and vibration
• Temperature Ranges -100 °C to 170°C
• Acceleration Range 3G’s to 100G’s

• Rapid Decompression:
• 21″ Diameter x 24″ long
• Transition rates up to 20,000 ft/sec
• Meets RTCA DO-160

• Blowing Rain
• Meets MIL-STD-810 and RTCA DO-160

• Dust Testing:
• 61″ x 42″ x 97″ chamber for settling dust
• Puff test
• Meets SAE J573

• Salt Fog Chamber:
• 48″ x 30″ x 36″
• Meets MIL-STD-810 Method 509.3, RTCA DO-160, and ASTM B117

• Thermal Vacuum Chamber (TVAC):
• 62″ in depth x 41″ Diameter.
• Plate is 36″ x 60″ with pressure to 1 x 10-6 Torr.
• Temperature range is -180 degrees C to 175 degrees C.

Standards / Specifications at Element Longmont

• AS/NZS CISPR 22
• ASTM
• CNS 13438
• EN 12184
• EN 55011 / CISPR 11
• EN 55014-1 and -2
• EN 55022 / CISPR 22
• EN 55024
• EN 55103-1 and -2
• EN/IEC: 61000-3-2
• EN/IEC: 61000-3-3
• EN/IEC/KN: 61000-4-11
• EN/IEC/KN: 61000-4-2
• EN/IEC/KN: 61000-4-3
• EN/IEC/KN: 61000-4-4
• EN/IEC/KN: 61000-4-5
• EN/IEC/KN: 61000-4-6
• EN/IEC/KN: 61000-4-8
• EN 61000-6-3
• EN 61000-6-4
• FCC Part 15
• FCC Part 18
• ICES-003
• KN 61000
• KN23 / KN35
• MIL-STD-1540
• MIL-STD-167
• MIL-STD-461
• MIL-STD-810
• MSFC-SPEC-521
• RTCA/DO-160
• SL-E-0002
• SSP 30237/8
• TCVN 7189
• VCCI
